Orbitron Core Manual
Mode - will select from 12 modulation FX. The 2 horizontal sliders (under the 3 knobs) control the character of the currently selected mode, they are exclusive to each mode. How they behave will depend on the selected mode. Below is a description of each mode and the associated character controls. Cosmic Chorus is a creative 4 voice chorus with delay and feedback for each voice. Vintage Chorus is a classic 2 voice chorus with a rich and fat sound. Super Chorus is a modern, clean and tight chorus. Tape Flanger is a classic analogue tape flanger. Future Flanger is a creative flanger with delay and feedback. Phat Phaser is a modern phaser that oscillates between 200Hz and 2kHz. Infinite Combs is a series of modulated comb filters that create the Shepard's tone effect. Liquid Filter is a morphable HP/LP filter with sweeping cutoffs. Kinetic Resonator is a filter with resonant peaks and modulating frequencies inside a feedback loop. Chaos Vortex is a multiband spinning effect, based on the doppler effect. Rotary Speaker Simulates a vintage rotary speaker cabinet. Space Time is a multiband and multitap array of modulated delay lines.
Depth - Controls the amount of effect. When at 0%, the FX engine is automatically bypassed to save CPU. Note this is not a simple Dry/Wet of the FX, rather it controls the actual strength of the FX. This is visually represented by the spinning coloured dot.
Rate - Controls the speed of the modulation. This is visually represented by the spinning coloured dot.
Width - This creates differences in the left and right channels. This is achieved differently for each mode, although mostly by offsetting the modulation phase, at 100% they will be 180 degrees out of phase.
Extra Controls - Every modulation effect boasts two unique special controls, allowing for nuanced adjustments and personalized sonic textures. Experiment with them to see what they do. ;)
Bypass - Disables the plugin's processing.
Activate - Opens a browser to locate the licence file to unlock the full version.
Wet - Controls the level of the processed signal.
Dry - Controls the level of the unprocessed signal.
Link - Makes "Wet" control "Dry" so that they both equal 100%. This is how most plugins work; however, here you can use the two controls unlinked to get 50% Wet and 100% Dry, for example.
Preset box - Uses the back and forward arrows to move between presets. Clicking in the box opens the preset browser, where you can save, load, and name presets.
Presets and left-right arrows
The plugin comes with a set of presets, which should do the trick for most cases or give you a good starting point when tweaking your sound. Access them using the Presets button. You can save and manage your own presets there as well. In your computer, presets are stored in the following paths:
Windows:
c:\Users\USER NAME\AppData\Roaming\UnitedPlugins\PRESETS\PLUGIN NAME
macOS X:
/Users/username/Library/Application Support/UnitedPlugins/PRESETS/PLUGIN NAME
Right-click menu
Right-click anywhere in the plugin background with the right mouse button, and you will get access to the following features.
Scale GUI precisely by per cent.
Get the version info.
Access the product web page, reach support and access online documentation.
Contact support
Open the presets folder (to add, arrange or delete presets manually)
Activate/Deactivate the plugin
Access Licence Manager (to activate or deactivate the plugin or several plugins at the same time)
Disable/Enable GPU Acceleration.
Disable/Enable Intelligent sleep on silence function that disables the plugin when no sound is on the input or output to save CPU power.
Right-click any control (knob, button) to access help for the particular parameter.
Installation and maintenance
Use UnitedPluginsManager (Downloads section) to install, uninstall, update and activate the plugin.
If you are in trouble, please contact us at support@unitedplugins.com.
Updating and Uninstallation
Updating or removing the plugin to the newest version is as simple as running the UnitedPlugins Manager.
Trial and activation
Use UnitedPlugins manager to activate and deactivate the plugin.
Support
Now that you’ve taken the time to learn all about Lofinity, enjoy and make your sound awesome! If our plug-ins helped you take your production to the next level, let us know, we’d love to hear from you and what you were able to create with our software.
If you encounter any problems, we offer free technical support for all registered users. Start with the frequently asked questions here:
http://www.unitedplugins.com/faq
If you need further assistance, you can find our Customer Support contact form at:
http://www.unitedplugins.com/contact
You can also reach our support staff by e-mail at:
support@unitedplugins.com
